PBB Duplex with double bourdon tube and two pointers
Enig resultaat
| Case | bayonet lock, AISI304/1.4301, IP-65 standard with blow-out |
| Wetted parts | double bourdon tube AISI316Ti/1.4571 |
| Window | mineral glass 4 mm |
| Dial | aluminium, black figures on white background |
| Pointer | two pointers, 1x black and 1x red, aluminium |
| Connection | Ø100 and Ø160 mm: 2x ½”BSP or ½”NPT |
| Movement | brass |
| Range | -1/0 and 0-0,6 – 60 bar, according to EN 837-1; for higher ranges (max. 1600 bar) |
| Accuracy | Ø 100 and Ø 160 mm± 1.0% F.S./class 1.0 |
| Application | general industry |
DOWNLOADS: Data sheet PBB Duplex with double bourdon tube and two pointers.pdf
PPB – The reliable dual gauge for precise measurements
A duplex gauge is a specialized type of gauge capable of performing and displaying two separate pressure measurements. It’s also known as a dual gauge and offers the ability to monitor or measure two different pressure values simultaneously. The duplex gauges from the PBB series are equipped with double Bourdon tubes for pressure measurement. The two pointers are located on a common dial.
This type of gauge is used in systems where it’s important to monitor or compare two pressure values simultaneously. For example, in applications such as hydraulic systems, gas and air pressure monitoring, or industrial process control. A duplex gauge offers the advantage of providing a simple and simultaneous display of two pressure values, which can make the monitoring and control of processes more efficient.
Contact
Are you in search of a stainless steel pressure gauge? EMVO Techniek can undoubtedly assist you with this. Our commitment to solutions and customer-centricity is central to delivering the desired product. For any inquiries, feel free to reach out to us. Our specialists are at your service. You can contact us at the following number: +31(0)413-473037. Found what you were looking for? Request a quote now.
